Transfer box - LT230SE

TORQUE WRENCH SETTINGS

06-11

Transfer box - LT230SE

† New nut must be fitted

* New Patchlok nut must be fitted

+ Apply sealant, Part No. STC 50552 to threads

TORQUE DESCRIPTION

METRIC

IMPERIAL

High/low selector cable

30 Nm

(22 lbf.ft)

Bottom cover plate bolts +

25 Nm

(18 lbf.ft)

Transfer box to gearbox bolts - Petrol and diesel +

 45 Nm

 (33 lbf.ft)

Rear cover plate stud nut/bolts +

25 Nm

(18 lbf.ft)

Differential lock warning lamp switch locknut - Up to 03 MY

11 Nm

(8 lbf.ft)

Differential lock warning lamp switches - 03 MY onwards +

25 Nm

(18 lbf.ft)

Drive flange nut

148 Nm

(109 lbf.ft)

Output shaft housing bolts +

45 Nm

(33 lbf.ft)

Oil temperature sensor - If fitted +

 25 Nm

(18 lbf.ft)

Inhibitor switch to transfer box

26 Nm

(19 lbf.ft)

Intermediate shaft nut †

88 Nm

(65 lbf.ft)

Intermediate shaft retaining plate bolt +

25 Nm

(18 lbf.ft)

Differential bearing retaining nut *

72 Nm

(53 lbf.ft)

Output flange nut

162 Nm

(119 lbf.ft)

High/Low selector housing bolts +

25 Nm

(18 lbf.ft)

Bearing housing/cover bolts +

25 Nm

(18 lbf.ft)

Blanking plug +

25 Nm

(18 lbf.ft)

High/Low selector warning lamp switch

25 Nm

(18 lbf.ft)

Differential lock selector housing bolts +

25 Nm

(18 lbf.ft)

Neutral sensor

25 Nm

(18 lbf.ft)

Interlock solenoid bolts - Up to 03 Model Year

10 Nm

(7 lbf.ft)
