Manual gearbox - R380

TORQUE WRENCH SETTINGS

06-10

Manual gearbox - R380

 + Apply sealant, Part No. STC 50552 to threads

TORQUE DESCRIPTION

METRIC

IMPERIAL

Bias spring adjustment plate bolts +

25 Nm

(18 lbf.ft)

Gearbox to  engine bolts

45 Nm

(33 lbf.ft)

Coolant pipe housing bolts

25 Nm

(18 lbf.ft)

Breather  pipe banjo bolt

15 Nm

(11 lbf.ft)

Gear lever extension clamp bolt

25 Nm

(18 lbf.ft)

Gearbox mounting bolts

85 Nm

(63 lbf.ft)

Gearbox mounting nuts

48 Nm

(37 lbf.ft)

Seal housing bolts

18 Nm

(13 lbf.ft)

Bearing sleeve bolts

25 Nm

(18 lbf.ft)

Fork bolt

7 Nm

(5.2 lbf.ft)

Reverse light switch

24 Nm

(18 lbf.ft)

Extension housing bolts +

25 Nm

(18 lbf.ft)

Gear selector housing bolts +

25 Nm

(18 lbf.ft)

Oil pump to housing Torx screws

6 Nm

(4.4 lbf.ft)

Gear change lever yoke Allen screw +

25 Nm

(18 lbf.ft)

5th  gear stake nut

350 Nm

(258 lbf.ft)

Spool retainer bolts

8 Nm

(6 lbf.ft)

Centre plate detent spring and ball Torx screw

25 Nm

(18 lbf.ft)

Selector lever to housing bolts +

25 Nm

(18 lbf.ft)

Clutch \ Bell housing bolts

73 Nm

(54 lbf.ft)
