Automatic gearbox - ZF4HP22

TORQUE WRENCH SETTINGS

06-12

Automatic gearbox - ZF4HP22

+ Apply sealant, Part No. STC 50553 to threads

TORQUE DESCRIPTION

METRIC

IMPERIAL

Selector lever to selector shaft nut

26 Nm

(19 lbf.ft)

Starter inhibitor switch bolts

10 Nm

(7 lbf.ft)

Engine to torque converter bolts - Td5 & V8 +

50 Nm

(37 lbf.ft)

Closing plate to  gearbox housing bolt - V8

7 Nm

(5.2 lbf.ft)

Fluid pump to intermediate plate bolts

10 Nm

(7 lbf.ft)

Intermediate plate Allen plugs (M14)

40 Nm

(30 lbf.ft)

Intermediate plate Allen plugs (M20)

50 Nm

(37 lbf.ft)

Oil cooler adaptors

42 Nm

(31 lbf.ft)

Extension housing bolts

25 Nm

(18 lbf.ft)

Oil sump to gearbox housing bolts

8 Nm

(6 lbf.ft)

Oil filter Torx screws

8 Nm

(6 lbf.ft)

Oil pick-up tube Torx screw

8 Nm

(6 lbf.ft)

Parking pawl guide Torx screw

10 Nm

(7 lbf.ft)

Pressure regulator to valve body assembly

8 Nm

(6 lbf.ft)

Lock-up solenoid valve, retaining fork Torx screw

8 Nm

(6 lbf.ft)

Lock-up solenoid valve assembly to valve body Torx screws

8 Nm

(6 lbf.ft)

Gearbox bell housing (intermediate plate and converter housing to gearbox casing) bolts

46 Nm

(34 lbf.ft)

Speed sensor bracket screws

8 Nm

(6 lbf.ft)
