Engine Td5 (page 2 of 2)

TORQUE WRENCH SETTINGS

06-3

+ Apply sealant, Part No. STC 50552 to threads

Rocker shaft bolts

32 Nm

(24 lbf. ft)

Timing chain adjustable guide bolt

25 Nm

(18 lbf.ft)

Timing chain cover bolts

27 Nm

(20 lbf.ft)

Timing chain cover to cylinder block stud

7 Nm

(5.2 lbf.ft)

Timing chain fixed guide Allen screw +

25 Nm

(18 lbf.ft)

Timing chain cover to cylinder head nut and bolt

25 Nm

(18 lbf.ft)

Timing chain fixed guide (M6) bolt

10 Nm

(7 lbf.ft)

Timing chain fixed guide (M10) bolt

45 Nm

(33 lbf.ft)

Timing chain lubrication jet bolt

10 Nm

(7 lbf.ft)

Timing chain tensioner

45 Nm

(33 lbf.ft)

Torque converter to drive plate (automatic transmission) bolts

50 Nm

(37 lbf.ft)

Turbocharger heatshield bolts

10 Nm

(7 lbf.ft)

Turbocharger oil feed pipe banjo bolt

25 Nm

(18 lbf.ft)

Turbocharger to exhaust manifold nuts

30 Nm

(22 lbf.ft)

Vacuum pump oil feed pipe to cylinder head union

10 Nm

(7 lbf.ft)

Viscous fan nut

45 Nm

(33 lbf.ft)

Fuel spill return pipe unions - if fitted

20 Nm

(15 lbf.ft)

TORQUE DESCRIPTION

METRIC

IMPERIAL
