Engine Td5

TORQUE WRENCH SETTINGS

06-2

Engine Td5

TORQUE DESCRIPTION

METRIC

IMPERIAL

ACE pump bolts

25 Nm

(18 lbf.ft)

A/C compressor bolts

25 Nm

(18 lbf.ft)

Alternator support bracket to cylinder head bolts

25 Nm

(18 lbf.ft)

Alternator/vacuum pump oil feed pipe union

10 Nm

(7 lbf.ft)

Camshaft cover to camshaft carrier bolts

10 Nm

(7 lbf.ft)

Camshaft sprocket to camshaft bolts

37 Nm

(27 lbf.ft)

Centrifuge cover bolts

10 Nm

(7 lbf.ft)

Centrifuge oil drain pipe to sump bolts (or nuts)

10 Nm

(7 lbf.ft)

Centrifuge to oil drain pipe bolts

10 Nm

(7 lbf.ft)

Centrifuge to oil cooler housing bolts

25 Nm

(18 lbf.ft)

CKP sensor bolt

10 Nm

(7 lbf.ft)

Coolant pipe bolt

50 Nm

(37 lbf.ft)

Connecting rod bolts, then a further 80

°

20 Nm

(15 lbf.ft)

Crankshaft pulley bolt

460 Nm

(340 lbf.ft)

Crankshaft pulley TV damper bolts

80 Nm

(59 lbf.ft)

Crankshaft rear oil seal housing bolts

10 Nm

(7 lbf.ft)

Cylinder head bolts initial tighten

30 Nm

(22 lbf.ft)

Cylinder head bolts final tighten, then a further 90

°

, then a further 180

°

 and finally a

further 45

°

65 Nm

(48 lbf.ft)

Dipstick tube to camshaft carrier bolt

10 Nm

(7 lbf.ft)

Drive plate (automatic transmission) to crankshaft bolts

115 Nm

(85 lbf.ft)

EGR pipe clamp to cylinder head bolt - if fitted

25 Nm

(18 lbf.ft)

EGR pipe Allen screws

10 Nm

(7 lbf.ft)

Engine mounting (front) to cylinder block bolts

48 Nm

(35 lbf.ft)

Engine mounting (front) to chassis nuts

85 Nm

(63 lbf.ft)

Engine mounting bracket (rear, LH & RH) to gearbox bolts

85 Nm

(63 lbf.ft)

Engine mounting bracket (rear, LH & RH) nuts

45 Nm

(33 lbf.ft)

Flywheel to crankshaft (manual transmission) bolts, then a further 90

°

40 Nm

(30 lbf.ft)

Front crossmember bolts

26 Nm

(20 lbf.ft)

Fuel connector block bolts

25 Nm

(18 lbf.ft)

Fuel cooler to inlet manifold bolts

25 Nm

(18 lbf.ft)

Gearbox housing to engine bolts

50 Nm

(37 lbf.ft)

Heater pipe to cylinder head bolts

25 Nm

(18 lbf.ft)

Main  bearing cap bolts then a further 90

°

33 Nm

(24 lbf.ft)

Oil cooler housing to cylinder block bolts

25 Nm

(18 lbf.ft)

Oil cooler pipe clip bolts

10 Nm

(7 lbf.ft)

Oil filter adaptor housing to oil cooler housing bolts

25 Nm

(18 lbf.ft)

Oil pick-up strainer Torx screws +

10 Nm

(7 lbf.ft)

Oil pressure switch

15 Nm

(11 lbf.ft)

Oil pump drive sprocket bolt +

25 Nm

(18 lbf.ft)

Oil pump pressure relief valve plug +

25 Nm

(18 lbf.ft)

Oil pump and stiffener assembly to cylinder block bolts

13 Nm

(10 lbf.ft)

Oil sump to cylinder block bolts

25 Nm

(18 lbf.ft)

Oil sump to gearbox bell  housing bolts

13 Nm

(10 lbf.ft)

PAS pump bracket bolts

27 Nm

(20 lbf.ft)

PAS pump pulley bolts

27 Nm

(20 lbf.ft)

Rocker arm adjusting screw locknuts

16 Nm

(12 lbf.ft)
