SLS calibration blocks (REAR SUSPENSION)

REAR SUSPENSION

ADJUSTMENTS

64-25

ADJUSTMENTS

SLS calibration blocks

$% 64.50.38

Fit

1. Connect TestBook to vehicle.
2. Ensure contact faces of calibration blocks LRT-

64-003/1 and LRT-64-003/2 are clean.

3. Using Testbook, operate the SLS system to

raise the body, position the calibration blocks
LRT-64-003/1 and LRT-64-003/2 between the
rear axle and the body, then lower the body
onto the calibration blocks. The calibration
blocks are handed and only fit one way.

Remove

1. Using Testbook, operate the SLS system to

raise the body, remove the calibration blocks
LRT-64-003/1 and LRT-64-003/2 from
between the rear axle and the body.

2. Disconnect TestBook from the vehicle.
