Wipers and washers

TORQUE WRENCH SETTINGS

06-20

Heating and air conditioning

Wipers and washers

TORQUE DESCRIPTION

METRIC

IMPERIAL

Heater assembly

16 Nm

(12 lbf.ft)

Compressor bolts

22 Nm

(16 lbf.ft)

Blower motor

19 Nm

(14 lbf.ft)

Compressor to mounting bracket bolts

25 Nm

(18 lbf.ft)

A/C pipes to compressor bolts

10 Nm

(7 lbf.ft)

Condenser pipe bolt

5 Nm

(3.7 lbf.ft)

Receiver drier to bracket bolts

5 Nm

(3.7 lbf.ft)

Adaptor block to receiver drier bolt

5 Nm

(3.7 lbf.ft)

Evaporator pipe bolts

5 Nm

(3.7 lbf.ft)

Dual pressure switch to receiver drier

10 Nm

(7 lbf.ft)

Air conditioning pipes to receiver drier bolts

5 Nm

(3.7 lbf.ft)

TX valve pressure pipe union

22 Nm

(16 lbf.ft)

Evaporator pipe to TXV valve

32 Nm

(24 lbf.ft)

Evaporator assembly to body bolts

16 Nm

(12 lbf.ft)

High and low pressure pipe, bolts

10 Nm

(7 lbf.ft)

Fuel burning heater Torx bolts

25 Nm

(18 lbf.ft)

TORQUE DESCRIPTION

METRIC

IMPERIAL

Link to motor spindle

7 Nm

(5.2 lbf.ft)

Front motor assembly

 2.5 Nm

(1.8 lbf.ft)

Spindle nut

 3 Nm

(2.2 lbf.ft)

Wiper arm nut

13 Nm

(10 lbf.ft)
