Rear suspension

TORQUE WRENCH SETTINGS

06-16

Rear suspension

TORQUE DESCRIPTION

METRIC

IMPERIAL

Wheel nuts

140 Nm

(103 lbf.ft)

Wheel hub to axle

100 Nm

(74 lbf.ft)

Damper to axle

125 Nm

(92 lbf.ft)

SLS height sensor link to radius arm

25 Nm

(18 lbf.ft)

Radius arm

230 Nm

(170 lbf.ft)

Transverse links to pivot housing

155 Nm

(114 lbf.ft)

Pivot housing to axle bolts

230 Nm

(170 lbf.ft)

Transverse link to chassis

140 Nm

(103 lbf.ft)

SLS height sensor

 6 Nm

(4.4 lbf.ft)

SLS compressor

25 Nm

(18 lbf.ft)

ACE actuator to short arm

185 Nm

(136 lbf.ft)

ACE actuator to long arm

48 Nm

(35 lbf.ft)

ACE actuator pipe cap nuts

29 Nm

(21 lbf.ft)

Anti-roll bar link - upper

50 Nm

(37 lbf.ft)

Anti-roll bar link - lower

100 Nm

(74 lbf.ft)

ACE long arm to torsion bar

180 Nm

(133 lbf.ft)
