Manifolds and exhaust systems - V8

TORQUE WRENCH SETTINGS

06-8

Manifolds and exhaust systems - Td5

Manifolds and exhaust systems - V8

TORQUE DESCRIPTION

METRIC

IMPERIAL

Front pipe to turbocharger

27 Nm

(20 lbf.ft)

Inlet manifold

25 Nm

(18 lbf.ft)

Tail pipe

25 Nm

(18 lbf.ft)

Fuel cooler

25 Nm

(18 lbf.ft)

EGR valve

10 Nm

(7 lbf.ft)

Exhaust manifold

25 Nm

(18 lbf.ft)

Exhaust manifold heatshield (M6) bolts

10 Nm

(7 lbf.ft)

Exhaust manifold heatshield (M8) bolts

25 Nm

(18 lbf.ft)

EGR pipe Allen screws

10 Nm

(7 lbf.ft)

TORQUE DESCRIPTION

METRIC

IMPERIAL

Intermediate pipe/silencer nuts

25 Nm

(18 lbf.ft)

Inlet manifold bolts - initial tighten

10 Nm

(7 lbf.ft)

Inlet manifold gasket clamp bolts

18 Nm

(13 lbf.ft)

Inlet manifold bolts - final tighten

51 Nm

(38 lbf ft)

Tail pipe

25 Nm

(18 lbf.ft)

Coolant outlet pipe

22 Nm

(16 lbf.ft)

Front pipe flange nuts

30 Nm

(22 lbf.ft)

Exhaust manifold

55 Nm

(40 lbf.ft)
