NAVIGATION SYSTEM: DESCRIPTION AND OPERATION (page 2 of 9)

NAVIGATION SYSTEM

DESCRIPTION AND OPERATION

87-21

Basic Settings Menu

Service Mode
The service mode is accessed from the basic settings menu, by pushing and holding the menu switch until the service
mode menu is displayed. On the service mode menu, various checks can be selected using the rotary controller.
Pushing the menu switch again returns the system to the main menu.

The service mode has four main functions:

l

To check that components are fitted and to determine their hardware/software levels

l

To perform a quick 'health check' of the major input signals to the system

l

To check for correct operation of the control switches

l

To check the status of the GPS reception.

Service Mode Menu

SET

Units

Language

D

km

110y

220y

550y

miles

GB

Other

Volume

Wp. radius

- 2

M86 6065

M86 6066

ON-BOARD  MONITOR

NAVIGATION / GRAPHIC
ELEMENT

VIDEO MODULE

GPS

Service Mode

SENSOR TEST
