Dampers and SLS height sensors (MAINTENANCE)

MAINTENANCE

PROCEDURES

10-27

Steering rod ball joints

Check

1. Check condition  of ball joints and dust covers,

and security of fixings.


 +

 TORQUE WRENCH SETTINGS,

Steering.

2. Attempt to move the ball joints forwards,

backwards, side to side and up and down. No
end float in any direction should be detected. If
end float is present, the ball joint must be
renewed.

Dampers and SLS height sensors

Check – Dampers

Front dampers

Rear dampers

1. Check dampers for security and signs of

leakage.
