TOWING

LIFTING AND TOWING

08-2

Before commencing work on underside of vehicle re-
check  security of vehicle on stands.

WARNING: Always chock the wheels when
jacking. The hand brake acts on the the
transmission, not the rear wheels, and may be
ineffective when the wheels are off the ground.

Reverse procedure when removing vehicle from
stands.

Hydraulic ramps
Use only a 'drive on' type ramp which supports a
vehicle by it's own road wheels. If a 'wheel free'
condition is required, use a 'drive on' ramp
incorporating a 'wheel free' system that supports
under axle casings. Alternatively, place vehicle on a
firm, flat floor and support on axle stands.

TOWING

Towing
The vehicle has permanent four wheel drive. The
following towing instructions must be adhered
to:

Towing on 4 wheels with driver
Turn ignition key to position '1' to release steering
lock.

Select neutral in main gearbox and transfer gearbox.

Secure tow rope, chain or cable to towing eye.

Release the handbrake.

The brake servo and power assisted steering
system will not be functional without the engine
running. Greater pedal pressure will be required
to apply the brakes, the steering system will
require greater effort to turn the front road
wheels. The vehicle tow connection should be
used only in normal road conditions, 'snatch'
recovery should be avoided.

Suspended tow
To prevent vehicle damage, front or rear
propeller shaft MUST BE removed, dependent
upon which axle is being trailed.

Mark propeller shaft drive flanges at transfer box and
axles with identification lines to enable the propeller
shaft to be refitted in its original position.
