IN CAR ENTERTAINMENT: DESCRIPTION AND OPERATION (page 6 of 7)

IN CAR ENTERTAINMENT

DESCRIPTION AND OPERATION

86-6-9

Inputs and outputs
The radio cassette player receives a mute signal from the telephone system if a call is received, when the call finishes
the mute is removed and the system resumes play. Inputs are also received from the steering wheel control system
(mid line and high line sytems). When the system is turned on, the high line systems radio cassette player:

l

sends a 'power on enable' to the power amplifier

l

sends an 'enable' signal to the radio headphone amplifiers.

On the high line system the radio cassette player also sends and receives signals from the CD-autochanger and rear
headphone amplifiers (if fitted). On high line systems the radio cassette player sends audio signals to the power
amplifier.

Remote radio steering wheel controls (midline and high line systems)
The remote radio control switch is located on the LH side of the steering wheel and is secured with two screws. The
wiring from the remote radio control switch plugs in to a connector that is part of the steering wheel rotary coupler.
Operation of the remote radio control switches allow the driver to control the ICE without releasing the steering wheel.
Volume, mode and selection functions can be carried out using the steering wheel mounted control switches. Control
inputs from the remote radio control switches are sent to the radio cassette player.

C0098

1

Telephone mute

Input

2

Steering wheel remote radio controls

Input

3

Steering wheel remote radio controls

Output

4

Permanent battery feed

Input

5

System enable

Output

6

Illumination

Input

7

Auxilary feed

Input

8

Earth

Input

C0921 (high line systems)

1

Radio headphone left channel

Output +

2

Radio headphone right channel

Output +

3

Telephone audio

Input +

4

Radio headphone left channel

Output -

5

Radio headphone right channel

Output -

6

Telephone audio

Input -

C0922 (high line systems)

7

Radio headphone active

Input

8

I-BUS communications

Input/Output

9

Audio amplifier spatial imaging enable

Output

10

Radio headphone LH remote control

Input

11

Radio headphone RH remote control

Input

12

Headphone remote controls feed

Output

C1354 (high line systems)

13

CD-autochanger audio left channel

Input +

14

CD-autochanger audio right channel

Input +

15

CD-autochanger audio earth

Output

16

CD-autochanger audio left channel

Input -

17

CD-autochanger audio right channel

Input -

18

Not Used

19

CD-autochanger I-BUS communications link

Input/Output

20

CD-autochanger permanent feed

Output
