Transfer box - LT230SE

GENERAL DATA

04-14

Transfer box - LT230SE

Type

LT230SE, two speed reduction with front and rear drives

Reduction ratios:

⇒

 High range

1.211 : 1

⇒

 Low range

3.32 : 1

Low range gear to high/low range hub clearance

0.05 to 0.15 mm (0.002 to 0.006 in)

High range gear to high/low range hub clearance

0.05 to 0.15 mm (0.002 to 0.006 in)

Mainshaft input gear bearing pre-load

0.05 mm (0.002 in)

Intermediate gear bearing pre-load

Torque intermediate shaft nut to 88 Nm (65 lbf.ft)
