Vacuum control unit - from 03MY

ENGINE MANAGEMENT SYSTEM - V8

REPAIRS 18-2-95

Vacuum control unit - from 03MY

$% 19.75.06

Remove

1. If fitted: Remove 2 nuts securing heat shield

and remove heat shield.

2. Disconnect vacuum hose from actuator.

3. Disconnect multiplug from control unit.
4. Release 3 rubber mounting securing control

unit to mounting bracket and remove control
unit.

Refit

1. Position control unit and secure mountings.
2. Connect multiplug and vacuum hose.
3. If fitted: Fit heat shield, fit nuts and tighten to

10 Nm (7 lbf.ft).
