Sealants

CAPACITIES, FLUIDS, LUBRICANTS AND SEALANTS

09-4

Gearbox oil
Manual Gearbox: Use Texaco MTF 94 oil for refill
and topping-up.

Automatic Gearbox: Use Texamatic 9226, ATF
Dexron 11D or Dexron 111 for refill and topping-up

Transfer box
Use Texaco Multi-Gear 75W/90R or oil meeting
specification API GL5.

Front and rear axles
Use Texaco Multi-Gear 75W/90R.

Air Conditioning
Use lubricating oil Nippon Denso ND-8.

General Greasing
Use Multipurpose Lithium Base Grease N.L.G.I.
consistency No. 2.

Bonnet latch
Lubricate cable and latch with oil.

Sealants

The following table lists those sealants which are
used during repair / overhaul procedures covered in
this manual; it is essential that the sealant specified
for a particular procedure is used at all times.

Component

Application

Land Rover

Part No.

Td5 Engine

Timing chain fixed

guide Allen screw

STC 50552

Td5 Engine

Camshaft cover

gasket joint line

STC 50550

Td5 Engine

Oil pick-up strainer

Torx screws

STC 50552

Td5 Engine

Oil pump drive

sprocket retaining

bolt

STC 50552

Td5 Engine

Timing chain cover,

crankshaft rear oil

seal and sump

gasket joint lines

STC 50550

Td5 Engine

Oil pressure relief

valve plug

STC 50552

Td5 Engine

Camshaft carrier to

cylinder head

STC 4600

Td5 Engine

Timing cover

STC 50550

V8 Engine

Sump gasket to

cylinder block

STC 50550

V8 Engine

'V' grooves at end

of cylinder head -

Inlet manifold

gasket

STC 50550

V8 Engine

Cruciform seal

ends

STC 50550

V8 Engine

Dipstick tube

STC 50554

V8 Engine

Timing cover bolts

STC 50552

Engine

Management

System - V8

Engine coolant

temperature (ECT)

sensor threads

STC 50552

Manifolds and

Exhaust

System - V8

'V' grooves at end

of cylinder head -

Inlet manifold

gasket

STC 50550

Manual

Gearbox -

R380

Gear selector

housing

STC 4404

Manual

Gearbox -

R380

Selector housing

bolts

STC 50552

Manual

Gearbox -

R380

Input shaft oil seal

housing

STC 4404

Manual

Gearbox -

R380

Reverse inhibitor

shaft threads

STC 50552
