Anti-Freeze Concentration

CAPACITIES, FLUIDS, LUBRICANTS AND SEALANTS

09-2

Fluids

Anti-freeze
Use Havoline Extended Life Coolant (XLC), or any
ethylene glycol based anti-freeze  (containing no
methanol) with only Organic Acid Technology (OAT)
corrosion inhibitors, to protect the cooling system

CAUTION: No other anti-freeze should be used
with Havoline Extended Life Coolant.

 The cooling system should be drained, flushed and
refilled with the correct amount of anti-freeze solution
at the intervals given on the Service Maintenance
Check Sheet.

After filling with anti-freeze solution, attach a warning
label to a prominent position on the vehicle stating
the type of anti-freeze contained in the cooling
system to ensure that the correct type is used for
topping-up.

Brake/Clutch fluid
Use only DOT 4 brake fluid.

PAS fluid
Use Texaco cold climate power assisted steering
fluid PSF 14315.

ACE fluid
Where ambient temperature falls below -20

°

 C (-4

°

F), use only Texaco cold climate power assisted
steering fluid PSF 14315. Where ambient
temperature remains above -20

°

 C (-4

°

 F), use either

Texaco cold climate power assisted steering fluid ,
Dexron 11 or Dexron 111 non-synthetic fluid.

Air conditioning
Use only refrigerant R134a.

Refrigerant oil
Use only Nippon Denso ND-oil 8.

Refrigerant oil absorbs water and must not be stored
for long periods. Do not pour unused oil back into the
container.

NOTE: The total quantity of refrigerant oil in the
system is 180 ml.

CAUTION: Do not use any other type of
refrigerant oil.

Anti-Freeze Concentration

The overall anti-freeze concentration should not fall,
by volume,  below 50% to ensure that the anti-
corrosion properties of the coolant are maintained.
Anti-freeze concentrations greater than 60% are not
recommended as cooling efficiency will be impaired.

The following recommended quantities of anti-freeze
will provide frost protection to -48

°

C (-53

°

F):

Engine - TD5

Engine - V8

Concentration

50%

Amount of Anti-freeze

4 litres

Concentration

50%

Amount of Anti-freeze

6.5 litres

13.5 pts (US)
