Fault effects and warning indications

Fault code,

OBD II

(TestBook)

Fault description

Effect

Warning lamp

illumination

MIL

Sport/

Manual

P0705

(14, 23)

* Gear position switch,
incorrect outputs

Maintains current gear in low range, limp
home mode in high range. Shift pressure to
maximum, harsh gear shifts/engagement.

On On

P0721

(21)

* Downshift safety
monitor prevented
downshift which would
have caused engine
overspeed

Maintains current gear in low range, limp
home mode in high range. Shift pressure to
maximum, harsh gear shifts/engagement.

On

On

P0722

(22)

* Torque converter
slipping

Maintains current gear in low range, limp
home mode in high range. Shift pressure to
maximum, harsh gear shifts/engagement.

On

On

P0731

(29)

* Ratio monitoring,
implausible 1st gear
ratio

No apparent effect

On

On

P0732

(30)

* Ratio monitoring,
implausible 2nd gear
ratio

No apparent effect

On

Off

P0733

(31)

* Ratio monitoring,
implausible 3rd gear
ratio

No apparent effect

On

Off

P0734

(32)

* Ratio monitoring,
implausible 4th gear
ratio

No apparent effect

On

Off

P0741

(5)

* Torque converter
lock-up clutch fault

May affect driveability.

On

Off

P0743
(7, 25)

* Torque converter
lock-up solenoid (MV
3), open or short circuit

Limp home mode in low and high ranges. Shift
pressure to maximum, harsh gear shifts/
engagement.

On

On

P0748

(10, 28)

* Pressure regulating
solenoid (MV 4), open
or short circuit

Limp home mode in low and high ranges. Shift
pressure to maximum, harsh gear shifts/
engagement.

On

On

P0753
(8, 26)

* Shift solenoid (MV 1),
open or short circuit

Limp home mode in low and high ranges. Shift
pressure to maximum, harsh gear shifts/
engagement.

On

On

P0758
(9, 27)

* Shift solenoid (MV 2),
open or short circuit

Limp home mode in low and high ranges. Shift
pressure to maximum, harsh gear shifts/
engagement.

On

On

P1562

(24)

* Battery supply below
9V while engine
running

Maintains current gear in low range, limp
home mode in range. Shift pressure to
maximum, harsh gear shifts/engagement.

Off

On

P1601

(4)

* ECU, EEPROM
checksum

Limp home mode in low and high ranges. Shift
pressure to maximum, harsh gear shifts/
engagement.

On

On

P1606
(3)

* EEPROM

No apparent effect

On†

Off

P1606

(6)

* Watchdog

No apparent effect

On

On

P1612

(2)

* Solenoid valves
power supply relay,
sticking closed or open
circuit

Limp home mode in low and high ranges. Shift
pressure to maximum, harsh gear shifts/
engagement.

On

On
