Bush - differential mounting - rear

FINAL DRIVE

51-8

REPAIRS

Bush - differential mounting - rear

$% 51.15.44

Remove

1. Raise vehicle on lift.
2. Disconnect battery earth lead.
3. Remove rear propeller shaft.

 +

 DRIVESHAFTS, REPAIRS, Propeller

shaft - rear.

4. Release clips securing differential breather

pipe to body.

5. Support rear differential on jack.

6. Remove 2 bolts and 1 nut and bolt securing

differential to sub-frame mountings.

7. Carefully lower jack, allow differential and drive

shafts to rest on lower suspension arms.

8. Rotate differential through approximately 135

°

for access and tie aside.

9. Note fitted position of bush and paint mark sub-

frame.
