Power assisted steering (PAS) system - bleed

STEERING

ADJUSTMENTS

57-1

STEERING

ADJUSTMENTS

Power assisted steering (PAS) system -
bleed

$% 57.15.02

Check

1. Clean PAS fluid reservoir around filler cap and

fluid level indicators.

2. Check power steering fluid, if aerated, wait until

fluid is free from bubbles then top-up reservoir
to 'UPPER' level mark with recommended fluid.

3. Fit reservoir filler cap.

Bleed

1. Remove filler cap from reservoir and fill to

'UPPER' level mark with recommended fluid.
Fluid must always be present in reservoir
during bleeding.

2. Start engine and allow to run at idle for 10

seconds. Stop engine.

3. Top-up steering fluid reservoir.
4. Start engine and turn steering fully to LH and

RH locks. Stop engine.

5. Top-up steering fluid reservoir.

6. Start and run engine for 2 minutes, turn

steering fully to RH and LH locks.

CAUTION: Do not hold steering at full lock
for longer than 10 seconds.

M57 1109
