Differential assembly

FINAL DRIVE

REPAIRS

51-3

REPAIRS

Differential assembly

$% 51.15.01

Remove

1. Position vehicle on lift.
2. Remove exhaust system.

 +

 MANIFOLD AND EXHAUST SYSTEM

- Td6, REPAIR, Exhaust system and
mountings.


 +

 MANIFOLD AND EXHAUST SYSTEM

- V8, REPAIRS, Exhaust system &
mountings.

3. Remove 8 nuts securing centre heat shield and

remove shield.

4. Remove 8 hexagonal headed screws securing

fuel tank heat shield and remove shield.

5. Reference mark propeller shaft and differential

to aid reassembly.

6. Remove 6 nuts securing propeller shaft to

differential flange.

7. Remove 2 nuts securing propeller shaft support

bearing, lower the propeller shaft, release
flange from differential then temporarily support
the bearing and secure with nuts.

8. Raise rear of vehicle and support under body.

WARNING: Do not work on or under a
vehicle supported only by a jack. Always
support the vehicle on safety stands.

9. Remove road wheels.

M47 0406
