Engine - Td6

GENERAL DATA

04-1

GENERAL DATA

Engine - Td6

General

Type

3.0 litre in-line direct injection diesel, 4 valves per cylinder, turbocharged
and intercooled

Cylinder arrangement

6 in-line, No. 1 cylinder at front of engine

Bore

84.00 mm (3.307 in)

Stroke

88.00 mm (3.465 in)

Capacity

2924 cm

3

 (178.4 in

3

)

Firing order

1 - 5 - 3 - 6 - 2 - 4

Compression ratio

19.0 : 1

Direction of rotation

Clockwise viewed from the front of the engine

Maximum power

130 Kw (172 bhp) @ 4000 rev/min

Dimensions:

⇒

 Length

778 mm (30.6 in)

⇒

 Width

676.6 mm (26.6 in)

⇒

 Height

800.3 mm (31.5 in)

Fuel injection system

Type

Common rail, direct injection fed by Bosch high pressure delivery pump

Maximum governed speed

4750 rev/min

Idle speed

790

±

 50 rev/min

Glow plugs

6 – 1 per cylinder, positioned centrally in portion inlet side.

Turbocharger

Garrett GT 2256V

Emissions standard

EU3 - Class N1, Group 3

Valve timing

Inlet valves:

⇒

 Opens

8

°

 BTDC

⇒

 Closes

28

°

 ABDC

Exhaust valves:

⇒

 Opens

36

°

 BBDC

⇒

 Closes

4

°

 ATDC

Lubrication

Type

Wet sump, pressure fed

Oil pump type

Crankshaft driven, eccentric rotor

Pump outer rotor to body clearance

0.080 to 0.156 mm (0.0031 to 0.062 in)

Filter type

Disposable canister with full flow by-pass

Relief valve opening pressure

4.2 bar (60.9 lbf.in

2

)

Low oil pressure switch opening pressure

0.2 to 0.6 bar (3.0 to 8.8 lbf.in

2

)

Minimum oil pressure at idle
Oil pressure at 3500 rev/min
Maximum regulated oil pressure

0.5 bar (7.0 lbf.in

2

)

Not less than 3.0 bar (43.5 lbf.in

2

)

4.2

±

 0.5 bar (61

±

 7.0 lbf.in

2

)

Cylinder head

Type

Aluminium alloy, gravity die casting

Port configuration

Cross flow

Maximum warp

0.03 mm (0.001 in)
