MAINTENANCETd6 Diesel engine underbonnet view
MAINTENANCE
PROCEDURES
10-1
MAINTENANCE
PROCEDURES
Td6 Diesel engine underbonnet view
1 Battery - LHD illustrated, RHD on opposite side
2 Microfilter/activated charcoal filter
3 Brake fluid reservoir - LHD illustrated, RHD on
opposite side
4 Screen/headlamp washer reservoir filler cap
5 Cooling system expansion tank filler cap
6 Power steering reservoir filler cap
7 Engine oil dipstick
8 Engine oil filler cap
9 Air cleaner
