TRANSFER BOX
11
DESCRIPTION AND OPERATION
Pin No.
Description
Input/Output
26
Motor drive - Clockwise
Output
27
Not used
-
28
Transfer box OBDII link
Output
29
Power earth
Input
30
Vehicle speed signal earth
Input
31
Motor position switch 3
Input
32
Motor switch position 2
Input
33
High/Low range select
Input
34
Park/Neutral (Auto) Neutral (Manual) Signal
Input
35
High range status line
Output
36
Neutral range status line
Output
