76 - CHASSIS AND BODYSUNROOF
CHASSIS AND BODY
1
DESCRIPTION AND OPERATION
SUNROOF
1. Wind deflector
2. Sunroof panel
3. Drain channel
4. Rear stop spring
5. Slide block
6. Spring
7. Sunshade
8. Frame
9. Guide assembly LH
10. Locator
11. Lifter block
12. Anti-rattle pad
13. Sunroof motor
14. Special key
15. Spacer
16. Insert
17. Cable assemblies
18. Wind deflector gasket
19. Guide gasket
20. Seal
21. Guide assembly RH
22. Cover
23. Lever
24. Sunroof panel attachment frame
