413-08 Information And Message Center: Description And Operation (page 5 of 18)

SELECTED

in message center

for more than 2 seconds and is

currently active

MUD RUTS PROGRAM

SELECTED

Mud-ruts program icon

illuminated in message

center

Advisory message. Terrain

Response Mud/Ruts special program

has been selected for more than 2

seconds and is currently active

None

GRASS GRAVEL

SNOW

Grass gravel snow

program icon illuminated

in message center

Advisory message. Terrain

Response rotary control has been

moved to the Grass Gravel Snow

position. Program will be selected

after 2 seconds

None

MUD-RUTS

Mud-ruts program icon

illuminated in message

center

Advisory message. Terrain

Response rotary control has been

moved to the Mud/Ruts position.

Program will be selected after 2

seconds

None

SAND

Sand program icon

illuminated in message

center

Advisory message. Terrain

Response rotary control has been

moved to the Sand position. Program

will be selected after 2 seconds

None

ROCK CRAWL

Rock crawl program icon

illuminated in message

center

Advisory message. Terrain

Response rotary control has been

moved to the Rock Crawl position.

Program will be selected after 2

seconds

None

PROGRAM CHANGE

IN PROGRESS

Selected special program

icon illuminated in

message center

Vehicle operating conditions prevent

selection of program. This may be

caused by ABS or DSC activity or

electronically controlled differential(s)

If operating conditions

change within 60 seconds,

selected program will be

activated. If message

caused by electronically

controlled differential(s)

overheat, allow differential(s)

to cool and attempt to

reselect program.

SUSPENSION FAULT

NORMAL HEIGHT

ONLY

Two chimes, amber

indicator permanently

illuminated.

A fault has been detected in the air

suspension system. Only normal

height is available.

Connect T4 to diagnose fault

SUSPENSION FAULT

MAX SPEED 50 km/h

or 30 MPH

Two chimes repeated

regularly. Red indicator

permanently illuminated.

A major fault detected in air

suspension system. Height cannot

be controlled correctly.

Connect T4 to diagnose fault

SLOW DOWN OR

VEHICLE WILL RAISE

Two chimes

Vehicle will rise automatically to

normal height from crawl (locked

access) height if vehicle speed

increases.

Ensure the vehicle speed

does not exceed 18.6 mph

(30 km/h)

SLOW DOWN OR

VEHICLE WILL

LOWER

Two chimes

Vehicle will automatically lower to

normal height from off road height if

vehicle speed increases.

Ensure the vehicle speed

does not exceed 18.6 mph

(30 km/h)

SUSPENSION WILL

RAISE WHEN SYSTEM

COOLED

One chime

Air suspension compressor is

cooling. Lifting will resume when

compressor has cooled.

None

SUSPENSION

VEHICLE RAISING

SLOWLY

None

Vehicle is lifting slowly because

reservoir is empty. Only displayed if

lift time exceeds 12 seconds. This is

not a system fault

None

SUSPENSION IN

EXTENDED MODE

One chime

Vehicle body has become trapped on

an obstacle. Alternates with next

message. Do not jack the vehicle

with the engine running. The

suspension will enter extended mode

and the message will appear.

None

RESET SUSPENSION
