Crankcase Vent Oil Separator Removal

Crankcase Vent Oil Separator (17.10.04)

Removal

Published : Aug 5, 2004

1 .

Disconnect the battery ground cable. For additional information, refer to

Specifications

 (Section 414-

00)

2 .

Remove the intake air shutoff throttle. For additional information, refer to

Intake Air Shutoff Throttle

(19.70.32)

 (Section 303-04)

3 .

  Disconnect the low-pressure fuel lines.

Install blanking caps to the exposed ports.

4 .

  Disconnect both exhaust gas recirculation (EGR) coolant cross-over pipe hoses.

Clamp the EGR coolant hoses to minimize coolant loss.

5 .

  Remove the EGR coolant cross-over pipe.

Remove the two retaining bolts.
