Rear View Mirrors
COMPONENT LOCATIONS
NOTE :
GENERAL
Rear view mirrors consist of an interior mirror on the windshield and an exterior mirror on each front door cheater.
Published : Oct 26, 2004
LHD model shown, RHD model similar
Item Part Number
Description
1
-
Exterior mirror
2
-
Interior mirror (auto-dimming version shown)
3
-
Exterior mirror control switch
4
-
Washer jets/exterior mirrors heater relay
5
-
Foldback module
