Catalytic Converter LH Removal

Catalytic Converter LH (17.50.03)

Special Service Tools


Wrench, HO2S
310-121 (LRT-19-014)


Removal

Installation

Published : May 11, 2004

1 .

Disconnect the battery ground cable. For additional information, refer to

Specifications

 (Section 414-

00)

2 .

   WARNING: Do not work on or under a vehicle supported only by a jack. Always support the

vehicle on safety stands.

  Raise and support the vehicle.

3 .

Remove the exhaust system. For additional information, refer to

Exhaust System (30.10.08)

(Section

309-00)

4 .

  Remove the catalytic converter.

Remove the nut and release the retaining clamp.

5 .

NOTE :

  Do not disassemble further if the component is removed for access only.

  Using the special tool, remove both HO2S from the catalytic converter.

1 .
