413-08 Information And Message Center: Description And Operation (page 4 of 18)

SYSTEM CHECK IN

PROGRESS

None

Instrument cluster internal diagnostic

routine

None

SYSTEM FAULT

SPECIAL PROGRAMS

NOT AVAILABLE

Single chime, general

program icon illuminated

in message center

Terrain Response special programs

not available due to system fault.

Drive off-road with care.

Connect T4 to diagnose fault

RECOMMEND LOW

RANGE IS SELECTED

FOR MUD-RUTS

PROGRAM

Mud-ruts program icon

illuminated in message

center

Advisory message for Terrain

Response special program displayed

once every ignition cycle

Select low range if required

RECOMMEND

STARTING IN 2ND

GEAR FOR SLIPPERY

CONDITIONS

Grass Gravel Snow

program icon illuminated

in message center

Advisory message for Terrain

Response special program (Only

displayed on vehicles with manual

transmission in low range, once

every ignition cycle)

Select 2nd gear if required

RECOMMEND

STARTING IN 3RD

GEAR FOR SLIPPERY

CONDITIONS

Grass Gravel Snow

program icon illuminated

in message center

Advisory message for Terrain

Response special program (Only

displayed on vehicles with manual

transmission in low range, once

every ignition cycle)

Select 3rd gear if required

RECOMMEND

RAISING

SUSPENSION TO OFF

ROAD HEIGHT IN

DEEP MUD-RUTS

Mud-ruts program icon

illuminated in message

center

Advisory message for Terrain

Response mud/ruts special program

when in high range, displayed once

every ignition cycle (Suspension
raised automatically when in low

range)

Raise suspension manually

to off-road height if required

Terrain Response

SPECIAL PROGRAMS

OFF

All five program icons

illuminated in message

center

Advisory message to inform driver

that Terrain Response special

programs are off

None

SPECIAL PROGRAMS

OFF

General program icon

illuminated in message

center

Advisory message to inform driver

that current special program has

been switched off and general

program is active

None

CAUTION! RISK OF
GROUNDING WITH

SUSPENSION AT

NORMAL HEIGHT

The active special

program icon will be

illuminated in message

center

Only displayed when system would

have normally provided off-road

height, but driver has manually
lowered the suspension (or the

suspension system is unable to raise

the vehicle)

Raise suspension manually

to off-road height if possible

and where appropriate

TRAILER

CONNECTED OFF

ROAD HEIGHT NOT

SELECTED

AUTOMATICALLY

The active special

program icon will be

illuminated in message

center

Advisory message displayed when

Terrain Response system would

normally have provided off-road

height automatically, but system has

detected an electrical load on trailer

socket

If trailer or light board is

connected, manually raise

suspension to off-road

height if safe to do so If
nothing is connected to

trailer socket, investigate

trailer socket and/or Terrain

Response system for fault

SELECT LOW RANGE

TO ACTIVATE ROCK

CRAWL

Single chime, rock crawl

program icon illuminated

in message center

Terrain Response Rock Crawl

special program has been requested

but transfer box is in high range

Change transfer box to low

range

SAND PROGRAM

SELECTED

Sand program icon

illuminated in message

center

Advisory message. Terrain

Response Sand special program has

been selected for more than 2

seconds and is currently active

None

ROCK CRAWL

PROGRAM SELECTED

Rock crawl program icon

illuminated in message

center

Advisory message. Terrain

Response Rock Crawl special

program has been selected for more

than 2 seconds and is currently

active

None

GRASS GRAVEL

SNOW PROGRAM

Grass gravel snow

program icon illuminated

Advisory message. Terrain

Response Grass Gravel Snow

special program has been selected

None
