Selector Lever Cable Adjustment

Selector Lever Cable Adjustment (44.30.04)

1 .


Check for correct cable adjustment.



2 .


Raise and support the vehicle.


3 .  Remove the transmission undershield.


4 .  If installed, remove the transmission heat shield.


5 .  Adjust the selector cable.

Published : Jan 6, 2005

   WARNING: The hand brake and foot brake MUST BE applied.

Move the selector lever from 'P' position, check engagement in each position and return to 'P'.

Check that the engine will start in 'P' and 'N' positions and that the engine start is inhibited when drive positions

are selected.

   WARNING: Do not work on or under a vehicle supported only by a jack. Always support the vehicle on

safety stands.

Remove the 6 bolts.

Remove the 4 bolts.

Using an additional wrench, restrain the clamping bush and loosen the locknut.
