413-08 Information And Message Center: Description And Operation (page 6 of 18)

HEIGHT IF CLEAR OF

OBSTACLE

None

Reselect height if door is open or

press switch to exit extended mode.

None

SUSPENSION

LOCKED AT ACCESS

HEIGHT

None

Crawl (locked access) mode

selected.

None

SUSPENSION

ACCESS HEIGHT

SELECTED

None

Access height selected.

None

SUSPENSION

NORMAL HEIGHT

SELECTED

None

Normal height selected.

None

SUSPENSION OFF

ROAD HEIGHT

SELECTED

None

Off road height selected.

None

SUSPENSION
REMOTE KEY

OPERATION

Continuous chime while

height is changing.

Air suspension remote control

function is being operated.

None

SUSPENSION CLOSE

DOOR TO CHANGE

HEIGHT

One chime

Air suspension height change is

prevented because a door is open.

Close all doors

SUSPENSION SPEED

TOO HIGH TO

CHANGE HEIGHT

One chime

A height change has been requested

but is prevented because speed is

too high.

None

SUSPENSION FAULT

Two chimes, amber

indicator permanently

illuminated.

A fault has been detected in the air

suspension system. System may still

operate normally.

Connect T4

SUSPENSION START

ENGINE TO RAISE

VEHICLE

One chime

Vehicle height can only be raised

with the engine running.

Start engine

KEY BATTERY LOW

PLACE IN IGNITION

TO CHARGE

None

Handset battery low

Place key in ignition to

charge

SUSPENSION FAULT

VEHICLE LEAN WHEN

CORNERING

Amber indicator lamp will

be permanently

illuminated

ACE system (if fitted) no longer

available. Vehicle is still driveable.

Connect T4 to diagnose fault

SUSPENSION FAULT

STOP SAFELY STOP

ENGINE

The red indicator lamp

will flash accompanied by

a chime

Major component failure, stop vehicle

immediately.

Connect T4 to diagnose fault

MEMORY 1
SELECTED

Double chime when

selection complete

Memory system - confirmation that

selection is completed

None

MEMORY 2
SELECTED

Double chime when

selection complete

Memory system - confirmation that

selection is completed

None

MEMORY 3
SELECTED

Double chime when

selection complete

Memory system - confirmation that

selection is completed

None

MEMORY 1 STORED

Single chime

Memory system - confirmation that

memory has stored driver information

None

MEMORY 2 STORED

Single chime

Memory system - confirmation that

memory has stored driver information

None

MEMORY 3 STORED

Single chime

Memory system - confirmation that

memory has stored driver information

None

DOOR MIRROR DIP

STORED

Single chime

Memory system - confirmation that

memory has stored driver information

None

DSC SWITCHED OFF

Amber indicator

permanently illuminated

System not available due to DSC

switched off by driver.

To reselect press DSC

switch

HDC FAULT SYSTEM

NOT AVAILABLE

One chime

System fault, drive with care and do

not attempt to descend steep slopes.

Connect T4 to diagnose fault

HDC TEMPORARILY

Wait until message is
