Automatic Gearbox - V8

TORQUE WRENCH SETTINGS

06-14

Automatic Gearbox - V8

TORQUE DESCRIPTION

METRIC

IMPERIAL

Fluid drain plug

25 Nm

18 lbf.ft

Fluid filler/level plug

35 Nm

26 lbf.ft

Selector cable trunnion nut

15 Nm

11 lbf.ft

Gearshift selector to carrier nuts

25 Nm

18 lbf.ft

Selector cable to selector lever nut

15 Nm

11 lbf.ft

Starter inhibitor switch bolts

10 Nm

7 lbf.ft

Starter inhibitor switch harness bracket bolt

10 Nm

7 lbf.ft

Starter inhibitor switch guard bolts

10 Nm

7 lbf.ft

Selector lever to inhibitor switch nut

10 Nm

7 lbf.ft

Selector shaft nut

10 Nm

7 lbf.ft

Shift solenoid retaining bracket Torx bolts

10 Nm

7 lbf.ft

Valve block Torx bolts

10 Nm

7 lbf.ft

Speed sensor to valve block clamp Torx bolt

10 Nm

7 lbf.ft

Multiplug bracket bolt

10 Nm

7 lbf.ft

 Gearbox to engine Torx bolts

45 Nm

33 lbf.ft

Fluid cooler banjo bolt

37 Nm

27 lbf.ft

Fluid cooler pipe union

37 Nm

27 lbf.ft

Fluid cooler saddle clamp bolt

6 Nm

4.4 lbf.ft

Drive plate to torque converter bolts

45 Nm

33 lbf.ft

Selector cable support bracket bolts

10 Nm

7 lbf.ft

Cross member bolts

68 Nm

50 lbf.ft

Mounting to cross member bolt

100 Nm

74 lbf.ft

Top bell housing Torx bolts

25 Nm

18 lbf.ft

Output flange housing to gearbox Torx bolts

10 Nm

7 lbf.ft

Sump Torx bolts

10 Nm

7 lbf.ft
