Automatic Gearbox - Td6

TORQUE WRENCH SETTINGS

06-13

 Automatic Gearbox - Td6

+ New plug must be fitted

TORQUE DESCRIPTION

METRIC

IMPERIAL

Fluid drain plug +

20 Nm

15 lbf.ft

Fluid filler/level plug +

20 Nm

15 lbf.ft

Selector cable trunnion nut

15 Nm

11 lbf.ft

Gearshift selector to carrier nuts

25 Nm

18 lbf.ft

Selector lever to selector shaft nut

10 Nm

7 lbf.ft

Detent spring bolts

10 Nm

7 lbf.ft

Selector cable support bracket to gearbox bolts

10 Nm

7 lbf.ft

Countershaft speed sensor Torx bolt

10 Nm

7 lbf.ft

Mainshaft speed sensor bolt

10 Nm

7 lbf.ft

Gearbox to engine Torx bolts:

l

M8

l

M12

25 Nm
72 Nm

18 lbf.ft
53 lbf.ft

Gearbox blanking plate Torx bolts

25 Nm

18 lbf.ft

Fluid cooler pipes to gearbox clamp bolt

25 Nm

18 lbf.ft

Intermediate plate to gearbox bolt

10 Nm

7 lbf.ft

Drive plate to torque convertor bolts

45 Nm

33 lbf.ft

Cross member bolts

68 Nm

50 lbf.ft

Mounting to cross member nut

100 Nm

74 lbf.ft

Bell housing top Torx bolts

72 Nm

53 lbf.ft

Extension housing bolts

10 Nm

7 lbf.ft

Sump bolts

10 Nm

7 lbf.ft

Fluid cooler bolts

10 Nm

7 lbf.ft

Fluid cooler pipe clamp bolts

10 Nm

7 lbf.ft

Valve body bolts

10 Nm

7 lbf.ft
