Gasket - oil sump

ENGINE - V8

12-2-104 OVERHAUL

Gasket - oil sump

$% 12.60.38.01

Remove

1. Remove dipstick.

2. Remove 2 nuts securing dipstick tube bracket

to camshaft cover.

3. Remove nut and clamp securing dipstick tube

to oil sump. Remove dipstick tube and sealing
washer. Discard 'O' ring.

4. Loosen 2 bolts securing ancillary drive belt

tensioner and release tension from the belt.

5. Remove ancillary drive belt.

6. Remove 2 Allen bolts and one nut securing

PAS pump, remove pump.

7. Remove oil pick-up strainer.

 +

 Engine - V8, OVERHAUL, Strainer -

oil pick up.
