Finisher - rear door

DOORS

REPAIRS 76-1-19

Finisher - front door

$% 76.42.05

Remove

1. Carefully release 12 clips securing finisher to

door.

CAUTION: Always protect paintwork when
removing or refitting any body trims or
bumpers.

2. Remove door finisher.

NOTE: Do not carry out further dismantling if
component is removed for access only.

3. Remove clips from door finisher.
4. Remove seal from door finisher.

Refit

1. Fit seal to finisher.
2. Fit clips to door finisher.
3. Fit and secure door finisher.

Finisher - rear door

$% 76.42.06

Remove

1. Open rear door, remove grommet and Torx

screw.

CAUTION: Always protect paintwork when
removing or refitting any body trims or
bumpers.

2. Carefully release 7 clips securing door finisher

to door, ease and break bonding tape on
feather edge.

3. Carefully remove door finisher.

NOTE: Do not carry out further dismantling if
component is removed for access only.

4. Remove door finisher retaining clips.
5. Remove seal from door finisher.

Refit

1. Fit seal to finisher.
2. Fit clips to finisher.
3. Clean finisher and door skin, remove all traces

of adhesive tape.

4. Position and secure adhesive tape to feather

edge of finisher.

5. Remove protective strip from adhesive tape.
6. Fit and secure door finisher.
7. Secure finisher with screw and fit grommet.

M76 4385
