Engine Management System – MEMS

TORQUE WRENCH SETTINGS

06-10

Engine Management System – MEMS

+ Apply sealant, Part No. STC 50552 to threads

TORQUE DESCRIPTION

METRIC

IMPERIAL

Camshaft position (CMP) sensor bolt

8 Nm

6 lbf.ft

Crankshaft position sensor (CKP) to housing bolt

8 Nm

6 lbf.ft

'E' box retaining clip nut

9 Nm

7 lbf.ft

Engine coolant temperature (ECT) sensor to housing bolt

*

15 Nm

11 lbf.ft

Fuel cut-off (inertia) switch nuts

2 Nm

1.5 lbf.ft

Idle air control (IAC) valve to manifold Torx screws

1.5 Nm

1.1 lbf.ft

Ignition coil and ht lead cover bolts

10 Nm

7.5 lbf.ft

Ignition coil mounting bolts

8 Nm

6 lbf.ft

Spark plugs to cylinder head

27 Nm

20 lbf.ft

Throttle body to inlet manifold chamber Torx screws (KV6)

7 Nm

5 lbf.ft

Throttle actuator support bracket to throttle body Torx screws
(vehicles with cruise control only)

9 Nm

7 lbf.ft

Throttle position sensor to housing Torx screws

1.5 Nm

1.1 lbf.ft
