Engine Management System – EDC

TORQUE WRENCH SETTINGS

06-9

Engine Management System – EDC

TORQUE DESCRIPTION

METRIC

IMPERIAL

Camshaft position (CMP) sensor Torx screw

8 Nm

6 lbf.ft

Crankshaft position (CKP) sensor Allen screw

8 Nm

6 lbf.ft

'E' box cover Allen screws

2 Nm

1.5 lbf.ft

Engine coolant temperature sensor (ECT)

15 Nm

11 lbf.ft

Engine breather pipe to air cleaner housing bolt

6 Nm

4.4 lbf.ft

Mass air flow / inlet air temperature MAF/IAT sensor to air cleaner housing

6 Nm

4.4 lbf.ft

Throttle pedal to stud nuts

25 Nm

18 lbf.ft

Throttle Position (TP) sensor nuts and bolts

10 Nm

7 lbf.ft

TP sensor release lever nut

10 Nm

7 lbf.ft
