Inhibitor switch - adjust (AUTOMATIC GEARBOX - JATCO)

AUTOMATIC GEARBOX - JATCO

ADJUSTMENTS

44-1

AUTOMATIC GEARBOX - JATCO

ADJUSTMENTS

Inhibitor switch - adjust

$% 44.15.18

Adjust

1. Set gear selector lever to 'N' position.

2. Loosen 2 bolts securing inhibitor switch to

gearbox casing.

3. Fit tool LRT-44-018 to selector lever on

gearbox, rotate inhibitor switch sufficient to
insert tool alignment pin through tool lever into
inhibitor switch.

4. Tighten inhibitor switch bolts to 3 Nm (2.2

lbf.ft)and remove LRT-44-018.

5. Check that the engine will start in 'P' and 'N'

positions and is inhibited when drive positions
are selected.

M44 1645A

LRT-44-018
