Engine Management System – Siemens

TORQUE WRENCH SETTINGS

06-11

Engine Management System – Siemens

TORQUE DESCRIPTION

METRIC

IMPERIAL

Camshaft position (CMP) sensor

8 Nm

6 lbf.ft

CMP sensor mounting bracket bolt

8 Nm

6 lbf.ft

Crankshaft position (CKP) sensor bolt

9 Nm

6.5 lbf.ft

Engine Coolant temperature (ECT) sensor

17 Nm

12.5 lbf.ft

'E' box cover Allen screws

2 Nm

1.5 lbf.ft

'E' box mounting nut

9 Nm

7 lbf.ft

Plug top coils to LH inlet manifold nut and bolt

9 Nm

6.5 lbf.ft

Plug top coils to RH camshaft cover bolts

9 Nm

6.5 lbf.ft

Spark plugs

25 Nm

18 lbf.ft

Throttle body to inlet manifold chamber Torx screws (KV6)

7 Nm

5 lbf.ft

Throttle pedal assembly to bulkhead nuts

25 Nm

18 lbf.ft

Throttle position (TP) sensor screws

1.5 Nm

1.1 lbf.ft
