Emission Control

TORQUE WRENCH SETTINGS

06-8

Emission Control

TORQUE DESCRIPTION

METRIC

IMPERIAL

Depression limiter valve and filter assembly Allen screws

8 Nm

6 lbf.ft

EGR cooler to mounting bolts

25 Nm

18 lbf.ft

EGR valve Allen screws

10 Nm

7.5 lbf.ft

EGR solenoid valve bolts

10 Nm

7.5 lbf.ft

EGR pipe to lifting bracket and cylinder head bolts

25 Nm

18 lbf.ft

Fuel rails to support bracket bolt

10 Nm

7.5 lbf.ft

Turbocharger outlet pipe to support bracket bolt

10 Nm

7.5 lbf.ft

Turbocharger pipe to coolant rail bolts

25 Nm

18 lbf.ft
