HEATER AND AIR CONDITIONING CONTROLS
- Make
- Land Rover
- Model
- Range Rover P38
- Section
- REPAIR › HEATER AND AIR CONDITIONING CONTROLS
80 - HEATING AND VENTILATIONHEATER AND AIR CONDITIONING CONTROLS
80
HEATING AND VENTILATION
NEW RANGE ROVER
10
REPAIR
Refit
14. Reverse removal procedure.
HEATER AND AIR CONDITIONING CONTROLS
Service repair no - 80.10.02
Remove
1. Move front seats to rearmost positions.
2. Remove 2 screws securing each side panel to
centre console. Release sprag clips from fascia
switch pack. Remove side panels.
3. Remove 4 screws securing control panel to
fascia. Release panel.
