80 - HEATING AND VENTILATION (DESCRIPTION): DESCRIPTION AND OPERATION (page 6 of 6)
- Make
- Land Rover
- Model
- Range Rover P38
- Section
- DESCRIPTION AND OPERATION
HEATING AND VENTILATION
7
DESCRIPTION AND OPERATION
Connector/
Pin No.
Description
Input/Output
C261 (up to
99MY)
C1597 (from
99MY)
1
RH temperature servo feedback reference voltage (-)
Input
2
Distribution servo feedback reference voltage (-)
Input
3
Not used
-
4
Distribution servo feedback reference voltage (+)
Output
5
RH temperature servo feedback reference voltage (+)
Output
6
Distribution servo voltage (+/-)
Input/Output
7
RH temperature servo feedback
Input
8
LH temperature servo feedback
Input
9
RH temperature servo voltage (+/-)
Input/Output
10
RH temperature servo voltage (+/-)
Input/Output
11
LH temperature servo voltage (+/-)
Input/Output
12
LH temperature servo voltage (+/-)
Input/Output
13
LH temperature servo feedback reference voltage (-)
Output
14
LH temperature servo feedback reference voltage (+)
Output
15
Distribution servo feedback
Input
16
Distribution servo voltage (+/-)
Input/Output
