77 - PANEL REPAIRSBODY DIMENSIONS · page 9 of 10
PANEL REPAIRS
9
BODY DIMENSIONS
ITEM
FROM
TO
DIMENSION
A
Load floor side - top tooling hole -
RH
Load floor side - top tooling hole -
LH
1360 (53.54)
B
Load floor side - top tooling hole
Crossmember rear tooling hole
377 (14.84)
C
Load floor side - bottom tooling
hole
Lower panel - tooling hole
474.8 (18.69)
