76 - CHASSIS AND BODYSEAT BELT ADJUSTABLE MOUNTING - ’D’ POST
background image

CHASSIS AND BODY

59

REPAIR

FRONT SEAT BELT ADJUSTABLE MOUNTING

Service repair no - 76.73.26

Remove

1. Remove ’B’ post trim upper.
2. Remove 2 screws securing adjustable mounting.

Remove mounting.

Refit

3. Position adjustable mounting. Secure with

screws. Tighten to

25 Nm. (18 lbf.ft)

4. Fit ’B’ post trim upper.

SEAT BELT ADJUSTABLE MOUNTING - ’D’ POST

Service repair no - 76.73.36

Remove

1. Remove ’D’ post trim - upper.
2. Remove 2 screws securing adjustable mounting.

Remove mounting.

Refit

3. Position adjustable mounting. Secure with

screws. Tighten to

25 Nm. (18 lbf.ft)

4. Refit ’D’ post trim - upper.
