76 - CHASSIS AND BODYEXTERIOR MIRROR
CHASSIS AND BODY
49
REPAIR
FRONT GRILLE
Service repair no - 76.55.03
Remove
1. Remove 6 screws securing grille.
2. Remove front grille.
Refit
3. Reverse removal procedure.
EXTERIOR MIRROR
Service repair no - 76.10.52
Remove
1. Release cheater panel, disconnect 2 tweeter
speaker connectors. Remove cheater panel.
2. Disconnect mirror multiplug.
3. Remove 3 screws, remove mirror.
Refit
4. Fit mirror, tighten 3 retaining screws.
5. Connect mirror multiplug.
6. Position cheater panel, connect 2 tweeter
speaker connectors, secure panel to door.
