THERMOSTAT

26

COOLING SYSTEM

NEW RANGE ROVER

6

REPAIR

THERMOSTAT

Service repair no - 26.45.01

Remove

1. Disconnect battery negative lead.
2. Raise the vehicle.

WARNING: Support on safety stands.

3. Remove cooling fan cowl.

See this section.

4. Release intake hose from ducting.

5. Release turbocharger intake hose from ducting.
6. Release breather valve from intake ducting

grommet.

NOTE: Collect grommet. Refit to ducting.

7. Disengage 2 clips securing intake ducting.

Remove ducting.

8. Remove 3 bolts securing intake ducting bracket

and exhaust manifold heat shield to camshaft
cover. Collect bracket.

9. Disconnect heater hose from coolant connecting

pipe.

10. Remove bolt securing coolant connecting pipe to

engine front cover.
