BRAKES

04

GENERAL SPECIFICATION DATA

NEW RANGE ROVER

16

INFORMATION

BRAKES

Front service brake
Caliper

Lucas Colette, single sided, two piston

..............................................................................

Operation

Power hydraulic, self-adjusting

.........................................................................

Disc

Reverse ventilated, outboard

..................................................................................

Disc diameter

297.2 mm (11.7 in.)

...................................................................

Disc thickness

25 mm (1 in.)

..................................................................

Wear limit

22.0 mm (0.87 in.)

.........................................................................

Disc run out maximum

0.15 mm (0.006 in)

.....................................................

Pad area

64.9 cm

2

(10 in

2

) per pad

..........................................................................

Total swept area

844 cm

2

(130.8 in

2

) per disc

...............................................................

Pad minimum thickness

2 mm (0.08 in.)

...................................................

Rear service brake
Caliper

Lucas Colette,single sided, single piston

..............................................................................

Operation

Power hydraulic, self-adjusting

.........................................................................

Disc

Solid, outboard

..................................................................................

Disc diameter

304.0 mm (12 in.)

...................................................................

Disc thickness

12.6 mm (0.5 in.)

..................................................................

Wear limit

11.7 mm (0.46 in.)

.........................................................................

Disc run out maximum

0.15 mm (0.006 in)

.....................................................

Pad area

34.4 cm

2

(5.33 in

2

) per pad

..........................................................................

Total swept area

798 cm

2

(123.7 in

2

) per disc

...............................................................

Pad minimum thickness

2 mm (0.08 in.)

...................................................

Parking brake
Type

Mechanical-cable operated drum brake on the rear

.................................................................................

of the transfer gearbox output shaft

Drum internal diameter

254 mm (10 in.)

.....................................................

Width

70 mm (2.75 in)

................................................................................

Anti-lock brake system
Manufacturer/type

Wabco/power hydraulic - 4 channel, 4 wheel sensed

............................................................

integrated anti-lock brake system.

ABS control

Microprocessor based ECU

......................................................................

System split

Front/rear

......................................................................

Power source

Electrically driven pump

...................................................................

Power storage

Hydraulic accumulator

..................................................................

Maximum boost pressure

180 bar

.................................................

Reservoir

Built in low fluid warning. Supplies clutch hydraulic

..........................................................................

system

Electronic traction control
Type

Integrated with ABS system

.................................................................................

ETC control

Integrated with ABS ECU

......................................................................
