AIR CONDITIONING

GENERAL SPECIFICATION DATA

15

INFORMATION

STEERING

Power steering box
Make/type

ZF type 8055, recirculating ball steering gear

........................................................................

Steering wheel turns, lock-to-lock

3.2

....................................

Steering pump
Make/type:

V8 engine

ZF type 7691, vane type

................................................................

Diesel engine

ZF type7681, vane type

..........................................................

Steering geometry
Steering wheel diameter

406.4mm (16 in.)

..................................................

Toe-out measurement

0.6 to 1.80mm (0.02 - 0.07 in.)

......................................................

Toe-out included angle

0

°

5’ to 0

°

15’

.....................................................

Camber angle

0

°

..................................................................

NOTE:

Castor angle

4

°

.....................................................................

Check at

Swivel pin inclination static

8

°

...............................................

kerbweight

SUSPENSION

Type:

Air suspension

Variable rate air springs controlled by an ECU giving 5

........................................................

height profiles. Automatic self levelling. Automatic
standard and low profiles. Driver selected access, low
and high profiles.
Lateral location of axle by Panhard rod.

Front

Fore and aft location by two radius arms.

.................................................................................

Lateral location of axle by a Panhard rod.

Rear

Fore and aft movement controlled by two trailing

.................................................................................

arms.
Lateral location of axle by a Panhard rod.

SHOCK ABSORBERS

Type

Telescopic, double-acting non-adjustable

.................................................................................

AIR CONDITIONING

System

CFC free expansion valve system

.............................................................................

Compressor

V8 up to 99MY

Sanden TRS105N

........................................................

V8 from 99MY and diesel

Nippon Denso 10PA17

........................................
