419-08 Cellular Phone: Description And Operation (page 7 of 8)

The Auto store feature instructs the radio to select the six strongest signals and allocate them against the auto store
presets.

There shall be nine preset memory locations within each of the following band settings, FM, FMA, AM, AMA, MW, MWA
and LW (only nine presets available for LW band therefore no Auto store available.

Voice commands will be available to allow the user to tune the radio to a given preset within the band that is currently
tuned.

Radio Directory

This function allows the user to nametag the current frequency and band including satellite radio (SDARS). Nametags are
user repeatable association names given to identify the frequency and band information thus allowing the radio to tune
into the desired signal. This facility shall allow 20 nametags to be stored within the voice recognition. It shall be possible
for the system to replay the whole of the directory with the ability to play or delete the stations announced. It should also
be possible to individually delete nametags.

Where nametags are part of the audible Feedback the corresponding Frequency and Band shall be displayed in text form
on the instrument pack message centre.


CD Changer

The CD changer system allows the following to be accessed and controlled by the voice recognition function.

The voice commands are standard control features with exception of controls that can be accessed on the steering wheel.
Commands shall be available for up to 256 tracks on a CD. Text numeric format shall be 3 numbers i.e. track 6 is
displayed as "006". MP3 Format discs have commands for Folder up/down. For additional information, refer to

Audio

System

 (415-01 Audio Unit)

Display

This function allows the user to change the TSD display mode by voice command.


Voice Recognition Settings

Voice Feedback On / Off

Allows the user to choose between having audible feedback or not for functions, other than some necessary functions,
which must have audible feedback to operate.

Replay

The replay command requests the voice recognition system to repeat it's last dialogue response within a list in both
audible and associated text feedback.

Notepad

The notepad function allows the user to record a series of 10 notes for up to 5 min.

The user shall be able to replay or delete the notes in the order that they were recorded. It shall also be possible to delete
the whole notepad.

TMC

The TMC system is part of the navigation system and provides real time traffic information to the navigation system. The
voice commands are On or Off. For additional information, refer to

Navigation System

 (419-07 Navigation System)



TMC also offers Dynamic route guidance. This is also a voice operated on/off function.


BLUETOOTH®
